Anti Rave is a modular free patching* synthesizer in compact format.

Building and expanding on the ideas of VCOOO- Spiked Pulsing Techno Rhythms, Additive Ambient Drone Textures, Hollow Flutes, Retro Game Sounds, Metallic Rave Stabs, Shifty Melodies, Poly Rhythmic Percussions are here to be excavated.

At center of Anti Rave are 4 VCOs and a 8 stage clock divider that divides a signal in halves all the way down to 1/256.
This however is not a typical clock divider. It also functions similar to a filter. This clock divider has an audio output and 2 exciter inputs.

Very interesting sounds can be had when the exciter is fedback some of the divide down outputs of the clock divider.

Here by using the two control parameters there are possible mellow almost acoustic like sounds, harmonically rich sounds typical of additive synthesis, all the way to harsh sounds like screaming mayhem.

***Free patching because with the exposed patching interface that you connect together with alligator clips - you can patch everything. Stack connections on inputs, on outputs, use finger touch, use metal wires or anything conductive, circuit bend, add additional components. Everything is opened up.

- 4 VCO oscillators - 2 low frequency only - 2 switchable between audio range and lfo.

- 2 Low Pass Gates for Audio or CV.

- 3 XOR Gates.

- Chaos register which generates stepped voltages (looped or free running) for modulating any of the other sections.

- Voltage Controlled Filtered White Noise Source with 3 different filter response outputs

- 45 patch points and 5 freely assignable 3.5mm mono jacks allow for deep user interface

- Comes with 10 alligator clip patch cables to get started and a USB 12v adapter cable that allows you to power the unit from any usb charger

- Physical Dimensions are 17cm x 17.7cm x 1.5cm (knobs excluded)

- Approx 500 grams

- All parts materials used in construction Lead Free ROHS compliant


DOWNLOAD ANTI RAVE USER MANUAL
